Model	Usage	Rated voltage (V)	Input power (W)	Capacity (kg)	Lifting speed (m/min)	Lifting height (m)	Cable length (m)	Package size (cm)	G.W./N.W. (kg)
PA500	single hook	220/230	900	250	10	12	12	52*42*17	35/33
	double hooks			500	5	6	12
PA600	single hook	220/230	1050	300	10	12	12	52*42*17	35/33
	double hooks			600	5	6	12
PA800	single hook	220/230	1300	400	10	12	12	52*45*17	39/37
	double hooks			800	5	6	12
PA1000	single hook	220/230	1600	500	10	12	12	53*48*18	33/32
	double hooks			1000	5	6	12

Thick copper wire motor, exclusive patented thermal design to ensure safe and stable operation (not to burn the motor)



Electric hoist also called civil electric hoist or small electric hoist, hanging electric hoist. Applicable to various occasions to lift small pieces of goods. Simple structure, easy installation, small and exquisite, and single-phase power as a power source, uses a wide range.

The minimum weight of the miniature electric hoist is 100KG and the maximum lifting weight is 1000KG. Single hook lift height up to 25 meters. Double hook up to 12 meters.

Scope of application:

Especially for high-rise buildings, households can easily lift from the downstairs inconvenient manual handling of daily necessities, and for a variety of occasions to lift small pieces of goods. Coupled with its easy installation and single-phase power 220V as a power source, simple and practical. This kind of civil electric hoist is widely used in machinery manufacturing, electronics, automobile, shipbuilding, workpiece assembly and high-tech industrial area and other modern industrial production lines, assembly lines, assembly machines, logistics and other occasions.

Instructions for use



1. Be sure to read the instructions before use. Micro electric hoist installation location must be selected to meet the requirements and easy to operate the place, to regularly check the micro-electricity Whether the installation of hoist is firm.



2. Do not overload the use, do not be lifting objects in the weight is not clear (including hanging buried objects. Cable, inclined, etc.) used. Overload will damage the miniature electric hoist Luhe (or) wire rope, increase the operation of the unsafe factors. When lifting heavy objects, it is recommended to use the pulley for double rope operation, so that you can Reduces the load on wire ropes and other major parts by 50%.



3. Please do not use it for a long time.



4. Micro-electric hoist at work, do not "stretch" was hanging objects, otherwise it will increase the load of micro-electric hoist, easy to micro-electric hoist and wire The rope is in an overloaded state.



5. Keep the mini electric hoist working area clean and tidy. Do not let loose people close, do not let anyone touch the tightening of the rope, is strictly prohibited any person standing Under the running state of the mini electric hoist.



6. If you need to replace the wire rope specifications must be consistent with the original wire rope.



7. When operating the wire rope, wear thick leather gloves and do not let the rope slip from the hands, otherwise it may damage your hand.



8. After the end of the operation will be rope rope income rope, do not hand directly to guide the wire rope sort.



9. Do not hook the rope itself with a hook, do not use micro-electric hoist wire rope, tied to hanging objects, otherwise it will damage the wire rope. In the tied to the hanging object Please use other suitable ropes.



10. The stopper is configured as a safety device which ensures that the rising circuit is automatically cut off when the hook is raised to the limit position. Please do not open the stopper as a stroke Off use.



11. Do not use mini electric hoist to lift people or for manned elevators.



12. Micro electric hoist installation location selection, to make warning signs and signs of signs in a striking state.



13. Ensure that the miniature electric hoist is operating without any trouble.



14. Do not operate the miniature electric hoist while drinking, taking medication and getting sick.



15. Micro electric hoist work, please do not work in the micro-electric hoist and around the work.



16. Use a solid accessory provided with a miniature electric hoist, which may cause you to be in an unsafe state.



17. Do not arbitrarily transform or welding micro-electric hoist parts, otherwise it will reduce the safety of micro-electric hoist.



18. When lifting the object with a miniature electric hoist, make sure that the rope is retained at least 3 turns on the rope to prevent the rope from falling off the rope when the force is too large.
