Tower Crane QTZ80H(TC5613)

Specification

Loading characteristic:

Radius		2.5-12.9	14	20	26	29	35	38	44	50	53	56
Counter weight(t)	2 falls	4	4	4	3.33	3.01	2.46	2.24	1.90	1.59	1.49	1.39
Counter weight(t)	4 falls	8	7.26	4.46	3.26	2.95	2.46	2.17	1.83	1.52	1.42	1.32

Technical performance parameters:

Rated/Max load moment			KN·m	824/1100
Max load capacity			t	8
Radius			m	2.5-51 2.5-56
Hoisting speed			m/min	80/40/9
Lifting height	Free standing		m	45
	Attached		m	160
Slewing speed			r/min	0.45-0.65
Luffing speed			m/min	60/30/10
Jacking speed			m/min	0.40-0.70
Tower crane dimension(m)	Undercarriage		㎡	2.6*2.6
	Fixed foundation		m³	5.55.51.35
	The whole height	Freestanding	m	52.3
		Attached	m	167.3
	Distance from boom tip to rotary center		m	52.36	57.36
	Distance from counter jib end to rotary		m	13.29
Others	Motor power		KW	42.4(without jacking motor)
	Max working pressure		Pa	250(Equivalent wind speed 20m/s)
	Max off working pressure		Pa	800(Equivalent wind speed 36m/s)
	Permitted working temperature		℃	-20~+40
Tower crane weight(t)	Structural weight	Freestanding	t	36.6	38.2
		Attached	t	87.6	89.2
	Counter weight		t	13.5	14.8

QTZ80H(TC5613) tower crane is upper rotating self-climbing tower crane for multipurpose with balance boom and trolley luffing. The appearance is elegant and popular in international and welcomed by the foreign customers. The free standing height is 45m and the height with anchor frame is 160m, when increasing the mast sections and anchor frames on free standing type. The height for the special made type can be up to 200m.
