Tower Crane QTZ63(TC5013)
- Mobile: 008613331906936
- Whatsapp: +8618358312481
- E-mail: admin@stronghoist.com
Load characteristic:
Techniacal performance parameters:
QTZ63(TC5013) crane is a kind of new tower crane desighed by our company for construction and it is upper rotating self-climbing tower crane for multipurpose, with balance boom and trolley luffing. The tower crane has large working scope, multi working model and wide applicable objects. It can work in free standing type and attached type to satisfy different construction requests.
| Rate | 2 falls | 4 falls | ||
| Tap plsition | Load capacity(t) | Speed(m/min) | Load capacity(t) | Speed(m/min) |
| Low, medium | 3 | 40,8.5 | 6 | 20,4.25 |
| High | 1.5 | 80 | 3 |
40 |
Techniacal performance parameters:
| Classification group of mechanisms | Hosting mechanism | M5 | ||||||
| Slewing mechanism | M6 | |||||||
| Drawing mechanism | M5 | |||||||
| Lifting height | Rate | Fixed(m) | Attached(m) | |||||
| a=2 | 40 | 140 | ||||||
| a=4 | 40 | 70 | ||||||
| Max load capacity(t) | 6 | |||||||
| Radius | Max radius(m) | 45,50 | ||||||
| Min radius(m) | 2 | |||||||
| Hoisting mechanism | Speed | Rate | a=2 | a=4 | ||||
| Load capacity(t) | 3 | 3 | 1.5 | 6 | 6 | 3 | ||
| Speed(m/min) | 8.5 | 40 | 80 | 4.25 | 20 | 40 | ||
| Motor model, power, rotate speed | YJZD225L-4/8/32-24/24.5/5.4KW-1410/710/150r/min | |||||||
| Slewing mechanism | Slewing speed | Motor model | Power(KW) | Rotate speed(r/min) | ||||
| 0-0.6 | YZR132M1-6 | 2*2.2 | 908 | |||||
| Drawing mechanism | Speed(m/min) | Motor model | Power(KW) | Rotate speed(r/min) | ||||
| 40.5/20 | YDEJ132S-4/8-B5 | 3.3/2.2 | 1440/720 | |||||
| Jacking mechanism | Speed(m/min) | Motor model | Power(KW) | Rotate speed(r/min) | ||||
| 0.5 | Y132S-4 | 5.5 | 1440 | |||||
| Working pressure | ＜16Mpa | |||||||
| Counter weight | Jib length(m) | Weight(t) | ||||||
| 45(m) | 11 | |||||||
| 50(m) | 12 | |||||||
| Weight | Self weight | Structure | t | 25.8(free standing height) | ||||
| Mechanism | t | 1.9 | ||||||
| Complete machine | Freestanding | t | 39.7(with counter weight) | |||||
| Attached | t | 68(with counter weight) | ||||||
| Working temperature(℃) |
-20~+40 |
|||||||
QTZ63(TC5013) crane is a kind of new tower crane desighed by our company for construction and it is upper rotating self-climbing tower crane for multipurpose, with balance boom and trolley luffing. The tower crane has large working scope, multi working model and wide applicable objects. It can work in free standing type and attached type to satisfy different construction requests.
